Deep Dive into Wireless

"A Deep Dive into Access Point (AP) Deployment and Configuration: Understanding WLC Modes and Bands"





Wireless Local Area Networks (WLANs) are essential components of today's technology-driven world. They are designed to connect wireless devices to a network, enabling users to access the internet and other network resources without the need for cables. One of the key components of a WLAN is the Access Point (AP), which acts as the bridge between wireless devices and the network. In this blog post, we will explore how an AP finds and joins a controller, the different modes of AP deployments, WLAN Controller (WLC) modes, the difference between 2.4 GHz and 5 GHz bands, and 802.1x authentication and deployment methods.

  1. How Access Point finds and tries to join a controller? An AP is designed to be autonomous, which means that it can function on its own without the need for a controller. However, to ensure optimal performance and centralized management, APs are often configured to join a WLC. When an AP is powered on, it goes through a boot-up process and tries to find a WLC to join. The AP uses a protocol called Lightweight Access Point Protocol (LWAPP) to discover and join a controller. The AP sends broadcast packets over the network to discover any available WLCs. When a WLC responds to the AP, it sends a join request to the WLC, and the WLC then sends a response with the necessary configuration information for the AP to join the network.

  2. Different modes of AP deployments There are two main modes of AP deployments: standalone mode and controller-based mode. In standalone mode, the AP operates independently without the need for a WLC. This mode is typically used in small networks where the number of APs is limited. On the other hand, in controller-based mode, the AP is managed and configured by a WLC. This mode is ideal for large networks where the number of APs is high, and centralized management is necessary.

  3. WLAN Controller (WLC) modes WLCs come in two main modes: local mode and FlexConnect mode. In local mode, the WLC directly manages and controls all APs in the network. This mode is ideal for small networks where the number of APs is limited. In FlexConnect mode, the WLC delegates some control to the AP, allowing the AP to operate in a standalone mode when the WLC is not available. This mode is ideal for large networks where the number of APs is high, and network coverage is spread over a large area.

  4. 2.4 GHz and 5 GHz bands APs operate in either the 2.4 GHz band or the 5 GHz band, or both. The 2.4 GHz band is a frequency band that has been used for wireless communication for many years. It has a longer range but is more susceptible to interference from other devices. The 5 GHz band, on the other hand, is a newer frequency band that provides faster speeds and less interference. However, the 5 GHz band has a shorter range compared to the 2.4 GHz band. When deploying an AP, it is important to consider the frequency band that will be used, as this will determine the range and speed of the wireless network.

  5. 802.1x authentication and deployment methods 802.1x is a standard for network access control that provides a secure method for users to access network resources. It requires that users provide a username and password or a certificate to access the network. There are different methods for deploying 802.1x, including central authentication, local authentication, and hybrid authentication. In central authentication,the authentication process is performed by a central authentication server, such as a RADIUS server. In local authentication, the authentication process is performed by the AP itself. Hybrid authentication combines both central and local authentication, providing a more flexible and secure authentication solution.

    In conclusion, understanding the AP deployment and configuration process is crucial for a successful WLAN deployment. APs play a crucial role in connecting wireless devices to the network, and they must be configured correctly to ensure optimal performance and security. Understanding the different modes of AP deployments, WLC modes, frequency bands, and 802.1x authentication methods will help you make informed decisions when deploying a WLAN. By following best practices and keeping up with the latest technology advancements, you can ensure that your WLAN is reliable, secure, and meets the needs of your organization.
